Select “digital barometer” in the test type list to start the quick test of digital barometer.
2. Connection
When testing the general digital barometer, connect to the calibrator as shown in Figure 5-6.
When testing the VAISALA digital barometer, it needs to connect the calibrator and the
communication interface as shown in Figure 5-7.
3. Start the test
Click the start button to select the automatic execution to enter the execution parameter
setting interface. Fill in the set point list, the number of cycles, the stroke mode, the number of
readings, the reading interval, and the dwell time, and then click the OK button to start the test.
In case of the general digital barometer, the readings need to be manually inputed during the test.
For the VAISALA digital barometer, the calibrator can automatically obtain the readings through
communication port.
Click the next button to skip the current set point and enter the next set point for pressure
control.
Selecting the manual execution requires manual input for each reading.
To stop this test, press the back button .
4. Save the result
Click the save button to save the test result.
