Accuracy
0.5%, 1%, 1.5%, 2%, 2.5%, 4%, and
custom
Precision of the pressure switch. The
numeral input in the custom option is
the precision level of the pressure
switch
Set point
Depends on the range of the pressure
switch
Operating point of the pressure switch
Action type
Normally closed, normally open
Action type of the pressure switch
Switch type
Mechanical switch, NPN switch, PNP
switch
Type of the pressure switch
Dead band
Depends on the range of the pressure
switch
Dead band range of the pressure switch
Owner
Letter, numeral, symbol
Owner of the pressure switch
Location
Letter, numeral, symbol
Locationof the pressure switch
Notes
Letter, numeral, symbol
Notes of the pressure switch
Table 5- 6 Task mode pressure switch information
3. Task setting
Select the task in the task list to enter the instrument parameter interface, click the start icon to enter
the execution information interface.
