45
hidden, the corresponding icon will be dim and when signals are being outputed, the output arrow on
the icon will flicker.
1. Changing the range
Click the range area on the left side of the measurement area to switch the output item. The calibrator
supports 0~25mA, 0~16V and 16~30V power output.
2. Connection: Connect the electric circuit as shown in Figure 3-14.
3. Enabling loop power (for current supply only)
According to the connection mode, press the key and select whether to enable loop power.
Power will be supplied as soon as loop power is enabled.
4. Input of the target set value
When the pressure output module is hidden, press the key to enter the setup interface of
electrical output values; When the pressure output module is hidden, press the / key or
press the key on the screen to realize step output of current, and set the step value inside .
The set value shall meet the calibrator's current output range of 0~25mA, voltage output range of
0~16V, and power output range of 16~30V.
5. Auto step
Press the key to enter the auto step setup. For the auto step parameters, see Table 3-5.
