46
Figure 3- 10 Current output of internal power supply
Item
Effective value
Description
Stroke
Round trip or one way
Set the trip pattern of auto step.
Cycle number
0-100
Set the cycle number of auto step.
Step mode
Step point,
percentage, value, or
custom
Set the mode of auto step.
Cycle interval
0~3600 sec
Standing time between the end of each cycle and the start of
next cycle.
Dwell time
0~3600 sec
Standing time after the present electrical output becomes
stable.
