102
1.6%, 2.5%, 4%, and
custom
Transfer function
Linear, square root
Type of transfer function of the I/P converter
Owner
Letter, numeral, symbol
Owner of the I/P converter
Location
Letter, numeral, symbol
Locationof the I/P converter
Notes
Letter, numeral, symbol
Notes of the I/P converter
Table 5- 7 Task mode I/P converter information
3. Task setting
For the contents, refer to Section 5.2.1 Task setting for calibration of the analog pressure gauge.
4. Task start
 For some contents, refer to Section 5.2.1 Task start for calibration of the analog pressure gauge.
 Enable or disable loop power as required
 If the external pressure module is connected, the internal module or the external module will be the
selected for the calibrated output standard;
 If the internal pressure range is selected, the pressure output range of the calibrated converter shall
not exceed the internal range of the calibrator;
 If the external pressure module is selected, the pressure output range of the calibrated converter
shall not exceed the range of selected external pressure module.
5. Task end
