104
Serial number
Letter, numeral, symbol
Serial number of the signal isolator
Model
Letter, numeral, symbol
Model of the signal isolator
Accuracy
0.05%, 0.1%, 0.2%, 0.5%,
1%, 1.5%, 2%, 2.5%, and
custom
Precision of the signal isolator.
Input
(0~25)mA, (0~16)V
Input current range or voltage range of the signal isolator
Output
(-50~50)mA, (-30~30)V,
(-300~300)mV
Output current range or voltage range of the signal
isolator
Transfer function
Linear, square root
Type of transfer function of the signal isolator
Owner
Letter, numeral, symbol
Owner of the signal isolator
Location
Letter, numeral, symbol
Location of the signal isolator
Notes
Letter, numeral, symbol
Notes of the signal isolator
Table 5- 8 Task mode signal isolator information
3. Task setting
For the contents, refer to Section 5.2.1 Task setting for calibration of the analog pressure gauge.
4. Task start
 For some contents, refer to Section 5.2.1 Task start for calibration of the analog pressure gauge.
