54
Figure 3- 14 Calibration of a 3-wire pressure transmitter
Figure 3- 15 Calibration of a 4-wire pressure transmitter
3. Manually set or use the step function (see Section 3.2.1 "Auto step and manual step of pressure
output") to output the pressure of each calibration point.
