6. Connectharddisk2tothepowersupply,andtotheSATA2connectoronthemotherboardwiththeSATA
cable(#16520877).

Caution!
DonotbendtheSATAcablestoosharplytopreventcabledamage.
ThetablebelowliststhecorrectdevicesandSATAconnectors:
Device SATA connector
DOM SATA0
HDD1 SATA1
HDD2 SATA2
7. IftheSATAcablesdonothavealockingmechanism,usetie-wrapstosecurethecablesonthedisk(s)in
thefollowingway:

8. Ifthereareunusedcablesleft,bundlethemwithtie-wraps.
