9. ClickSerial Settings,andsettheparametersasshowninthescreenbelow.
MakesurethatthePort Settings areasfollows:
Item Description
Protocol RS485-2wire
Flow control None
Baud rate 9600
Data Bits 8
Parity Even
Stop Bits 1
10. ClickOK tosavethesettings.
Next,youwillsetupthemoduletouseUDPcommunication.
