ADT NVR4200 Series User Manual

Hybrid Standalone NVR User Guide 3 Local Menu Operations
To activate the Preset:
1. In the main PTZ control panel, enter the Preset No. you want to playback into the No. field,
using the numeric keypad.
Figure 3-67
2. Click to initiate the selected preset. The camera moves to that Preset location.
Click again to stop the movement.
Tour
Presets can be strung together to move the camera in a designed movement called a Tour.
Figure 3-68
To setup the Tour:
1. In the Main PTZ Control panel, select the Tour tab.
2. Set the Patrol (tour) No. (for example, “1” in the above sample image).
3. Input a Preset number you want to add to the tour (for example, “3”).
4. Click Add Preset to add Preset 3 to Tour 1.
5. Return to step 3 to add other presets in the order you want them to occur.
NVR4200 Series User Guide
97
