Hybrid Standalone NVR User Guide 3 Local Menu Operations
To activate the Tour:
1. In the main PTZ interface, enter the Tour number you want to play back into the No. field,
using the numeric keypad.
Figure 3-69
2. Click to initiate the selected Tour.
The camera moves to all Preset locations that were set in the selected Tour. Click again
to Stop, enabling you to allow the Tour to run in its entirety or stop it at any time.
Pattern Setup
A pattern is much like a tour but does not use presets. Instead, the Pattern is recorded by the camera
movement design that you record using the Direction Keys on the Main PTZ Control panel. The
camera mimics the movement you recorded during setup.
Figure 3-70
To setup the Pattern:
1. In the Main PTZ Control screen, click the Pattern tab.
2. Click in the Pattern field and enter a value for this Pattern number.
3. Now click the Begin button to start recording your pattern.
NVR4200 Series User Guide
98
