2. SYSTEM COMPONENTS
2.1 Shelf
Total Access 3000/3010 is composed of four main elements:
• Total Access 3000/3010 Shelf and Backplane
• System Controller Unit Module
• Multiplexers
• Access Modules
The system houses the management, multiplexer modules, and access modules. The
compact shelf includes all the features necessary for total system functioning including
provisioning, protection, monitoring, alarm status, and optical fiber routing. The single
multifunction backplane provides for a variety of system arrangements.
The Total Access 3000/3010 shelf is compliant with all applicable NEBS Level 3
requirements and listed to UL 60950.
All modules are inserted and removed from the front of the shelf. The far-left slot is
designated for the System Controller Unit (SCU), the next two slots are designated for
Multiplexer Modules, and the remaining 28/22 slots are reserved for access modules.
Slot openings are labeled for easy identification and the access module slots are
numerically linked for optional protection pairing.
The 6-inch high, 12-inch deep, 23-inch/19-inch wide shelf is constructed of heavy
gauge sheet metal with vent perforations on the top and bottom planes. Construction
provides for all standard wire runs. Reversible mounting brackets allow for flush
mount or 5-inch overhang configurations. Mounting brackets meet either the 1-inch or
1 3/4-inch mounting hole pattern (see Figure 1).
Figure 1. Front View of Shelf
