Total Access
®
3000/3010 System Manual
6TADLP713-1E
TOTAL ACCESS 3000/3010
DLP-713
Page 2 of 4
© 2002, ADTRAN, Inc.
Perform Steps Below in the Order Listed
1.2 Detailed Level Procedure 713
1. Mount the modem to be used with Total Access 3000/3010 in its permanent
position.
2. Connect power to the modem per manufacturer’s instructions.
3. Configure the modem to be used as follows:
• Speed 9600 bps
• Data bits 8
• Parity none
• Stop bits 1
• Flow control off or none
• Auto answer on
• DTR ignore
• RTS ignore
4. Connect the male DB-25 connector end of the data cable to the female DB-25
connector, J31/J18, labeled “ADMIN,” located on the upper right corner of
the Total Access 3000/3010 backplane; screw down the cable.
5. Route the data cable to the modem.
6. Connect the other end of the cable to the modem configured as described
above.
7. Connect the modem to POTS line as required by the manufacturer.
CAUTION
Electronic modules can be damaged by static electrical discharge. Before
handling modules, wear an antistatic discharge wrist strap to prevent damage
to electronic components. Place modules in antistatic packing material when
transporting or storing. When working on modules, always place them on an
approved antistatic mat that is electrically grounded.
