6TADLP742-1E
TOTAL ACCESS 3000/3010
DLP-742
Page 9 of 14
Total Access
®
3000/3010 System Manual © 2003, ADTRAN, Inc.
Perform Steps Below in the Order Listed
1.5 Protection Configuration Provisioning
This provisioning option allows the user to set a Protection Configuration state of the
OC-3 MUX. If the MUX is in a single configuration, please continue this procedure at
Section 1.6, Channel Mapping Provisioning.
1. From the Primary MUX Main Menu select option 7, Protection Configuration, and
press <Enter>.
2. From the Protection Configuration Menu select option 2, APS Lockout Status, and
press <Enter>. This option indicates whether the module is “Allowed” to
automatically switch to the protection MUX or is “Inhibited” from switching to the
protection MUX.
1. Inhibit
2. Allow
Select the desired option by typing the corresponding number and press <Enter>.
3. Return to the Primary MUX Main Menu by pressing <Esc> and proceed to the
next section.
