Total Access
®
3000/3010 System Manual
6TADLP715-1E
TOTAL ACCESS 3000/3010
DLP-715
Page 2 of 4
© 2002, ADTRAN, Inc.
Perform Steps Below in the Order Listed
1.2 Detailed Level Procedure 715
1.2.1 Connecting a VT100 Terminal to Total Access 3000/3010
1. Set the parameters of the VT100 terminal to:
• 9600 baud rate
• 8 data bits
• No parity
• 1 stop bit
• No flow control
2. If the terminal has a parallel setting, disable it and use serial setting.
3. If you are using the rear Total Access 3000/3010 ADMIN connector,
use a null modem cable with a male DB-25 connector on the Total
Access 3000/3010 end.
4. If you are using the front craft port, use a serial cable with a male
DB-9 connector on the Total Access 3000/3010 end.
5. Plug the male end of the data cable into the Total Access 3000/3010
shelf. Make connection to the VT100 terminal as appropriate for
your equipment.
1.2.2 Connecting a Personal Computer Emulating a VT100
Terminal to Total Access 3000/3010
Most personal computers or laptops can run communications software that will
emulate a VT terminal. Windows programs such as Terminal or Hyperterminal are two
such examples in the Windows format, but there are many other adequate,
commercially available software packages, virtually all of which will allow your PC or
laptop to emulate a VT100 terminal. Certain configuration items must be set on a PC
or laptop to act as a VT100 terminal for Total Access 3000/3010.
