6TANTP504-1E
TOTAL ACCESS 3000/3010
NTP-504
Page 4 of 4
© 2003, ADTRAN, Inc.
Total Access
®
3000/3010 System Manual
3. Proceed to DLP-740 for procedure to provision the DS3 MUX modules.
4. Go to ATP-602 for the DS3 MUX Module Acceptance Testing Procedure.
5. Continue with Section 1.5 of this document when acceptance testing is complete.
1.5 Placing the Units in Service
NOTE
Ensure all alarms are cleared before placing the modules In-Service. This will
prevent false alarm from being transmitted to the network.
1. From the working MUX Menu, select option 2, Provisioning, and press <Enter>.
2. From the Provisioning Menu, select option 4, Service State, and press <Enter>.
3. From the Service State Menu, select option 1, In Service, and press <Enter>.
4. Repeat the above steps for the Protect MUX.
NOTE
At this point the POWER LED on both MUX modules will illuminate
GREEN, indicating an In-Service state. Alarms will also be generated in this
state. MUX A ONLINE LED should be illuminated green and MUX B
ONLINE LED should be off. The STATUS LED on both MUX units should
be green if a DS3 signal is present and synchronized. If no DS3 signal is
present, both LEDs will be illuminated red.
1.6 Follow-up Procedure
Please proceed to the appropriate NTP for the installation of the access modules to be
installed in the Total Access 3000/3010 chassis.
