6TANTP501-1E
TOTAL ACCESS 3000/3010
NTP-501
Page 15 of 22
Total Access
®
3000/3010 System Manual
© 2002, ADTRAN, Inc.
To connect the Total Access 3000/3010 shelf to the Ethernet ring, simply plug the
male RJ45 modular connector into the female RJ45 port on the Total Access 3000/
3010 backplane. When planning your cable run to the Total Access 3000/3010 shelf,
be sure to allow enough cable for routing the cable to the right from the backplane
connector to the frame, and for neat tie-off in accordance with CO SOP.
1.14 Install the SCU
The Total Access 3000/3010 System Controller Unit (SCU) is the focal point for all
management functions carried out by the shelf, and has the greatest number of
considerations when installing. The individual steps in this section detail these
considerations for a successful and trouble-free Total Access 3000/3010 installation.
The SCU handles local management and alarms, provides a craft interface for
provisioning individual access modules and multiplexers, and can be configured as a
host SCU to daisy chain up to 16 Total Access shelves together for management from
a single local craft interface. It can be identified by its part number, 1181018L1,
printed on the front of the faceplate underneath “SCU.”
The SCU also has a built-in X.25 PAD and an Ethernet interface for TL1/NMA or
SNMP management. The SCU can also be accessed by modem through the ADMIN
port, J31/J18.
