1.14.1 Install the SCU in Total Access 3000/3010
CAUTION
Electronic modules can be damaged by static electrical discharge. Before
handling modules, wear an antistatic discharge wrist strap to prevent damage
to electronic components. Place modules in antistatic packing material when
transporting or storing. When working on modules, always place them on an
approved antistatic mat that is electrically grounded.
NOTE
At this point in the Installation and Turn-up Procedure, power should not be
applied.
1. Pull the ejector on the bottom of the SCU faceplate from its stowed, or closed,
position. The Total Access 3000/3010 SCU can only be inserted into the first or far
left slot of the shelf. Attempting to insert the SCU in any other slot may damage
the SCU and/or the backplane.
2. Gently but firmly push the SCU into the first slot on the left of the shelf. The first
slot is labeled for the SCU. Simultaneous thumb pressure at the top (above the
four-character display panel) and bottom (below the DB-9 craft port) of the SCU
will ensure a good seat of the SCU pins into the backplane connector.
3. Push the ejector up and closed against the SCU faceplate.
1.14.2 Insert Blank Faceplates
Insert blank faceplates into MUX and access modules slots which will not be used.
Blank face panel (P/N 1181952L1) will cover the two empty MUX slots. For the 28/
22 empty access module slots, use blank face panel (P/N 1181953L1). These panels
are to be removed when installing a MUX, Cell Switch Module, or access module.
This procedure ensures maximum cooling efficiency for the shelf.
1.14.3 Apply Power and Verify the SCU Self-Test Passes
All power, ground and administrative connections should now be completed on the
Total Access 3000/3010 shelf, and an SCU (the only mandatory card for any Total
Access 3000/3010 function) should be installed in the shelf. This step applies power
to the shelf with an SCU in place, and ensures that the SCU properly powers up and
successfully completes its power-on self-test routine.
