Total Access 3000/3010 System Manual
6TADLP728-1E
TOTAL ACCESS 3000/3010
DLP-728
Page 4 of 4
© 2003, ADTRAN, Inc.
Perform Steps Below in the Order Listed
16. Confirm Reboot by typing <Y> and <Enter>.
This will not disrupt service on the Total Access 3000/3010. The SCU will restart
and the upgrade is complete. The firmware version that is currently installed may
be checked by viewing the Configuration Menu of the SCU.
1.3 Upgrading the SCU Using the Y-modem Protocol
1. Save the new firmware file onto the computer that is being used to control the
upgrade.
2. Logon to the SCU
For details, go to: DLP-716.
3. From the Total Access main menu, select System Controller Unit, and press
<Enter>.
4. From the System controller Unit menu, select Provisioning, and press
<Enter>.
5. From the Provisioning menu, select SCU/System Administration, and press
<Enter>.
6. From the System Administration menu, select Software Update, and press
<Enter>.
7. From the Software Update menu, select Y-modem Update, and press <Enter>.
8. Press <Y> and <Enter> to initiate the download.
The Software Upload screen will appear and state “Expecting a Y-modem
transfer”, use the communication program being run on the computer to send the
new firmware file to the SCU. Make sure that Y-modem transfer is selected as the
protocol for the communication program.
9. Select Reboot SCU, and press <Enter>.
10. Confirm Reboot by typing <Y> and <Enter>.
This will not disrupt service on the Total Access 3000/3010. The SCU will restart
and the upgrade is complete. The firmware version that is currently installed may
be checked by viewing the Configuration Menu of the SCU.
1.4 Follow-up Procedure
This completes the procedure for upgrading the Total Access 3000/3010 SCU. Return
to the document from which this procedure was called and continue.
