6TASYS101-1E
TOTAL ACCESS 3000/3010
SYS-101
Page 11 of 46
Total Access
®
3000/3010 System Manual
© 2003, ADTRAN, Inc.
Flag F. DSX Network Access
DSX-1 level I/O network side access is achieved through the 64-pin/50-pin amphenol
connectors for the access modules.
3.4 Loop Interfaces
Flag G. Loop Access
Loop side access is achieved via 64-pin/50-pin amphenol connectors for HDSL,
HDSL2, ISDN, T1, and DS1.
3.5 Test Access
Flag H. Loop Test Access
Six wire-wrap connections provide metallic loop testing access to the customer loops.
Flag I. DSX-1 Test Access
Six wire-wrap connections provide digital loop testing access to the customer loops.
3.6 Management Interfaces
Flag J. Network Management Port
DB-25 female connector allows port access for an X.25 connection.
Flag K. Administrative Port
Female DB-25 local access port to VT100 terminal, modem, or other serial device for
permanent provisioning and troubleshooting.
Flag L. RJ-45 for 10BaseT
RJ-45 jack provides for TCP/IP (Telnet, SNMP, TFTP) communication over 10BaseT.
Flag M. RS-485
Set of wire-wrap pins provides a bus for TL1 intershelf management. Up to 32
additional devices can be daisy-chained to the first shelf at a total distance of 4000
feet.
3.7 Alarms
Flag N. Audiovisual Alarms
The shelf provides for eight alarm outputs:
• Critical Visual
• Critical Audible
• Major Visual
• Major Audible
• Minor Visual
• Minor Audible
• AUX 1
• AUX 2
