ADTRAN Total Access 3000 - 1.2 Detailed Level Procedure 744

Total Access
®
3000/3010 System Manual
6TADLP744-1E
TOTAL ACCESS 3000/3010
DLP-744
Page 3 of 12
© 2003, ADTRAN, Inc.
Perform Steps Below in the Order Listed
CAUTION
Electronic modules can be damaged by static electrical discharge. Before
handling modules, wear an antistatic discharge wrist strap to prevent damage
to electrical components. Place modules in antistatic packing material when
transporting or storing. When working on modules, always place them on an
approved antistatic mat that is electrically grounded.
1.2 Detailed Level Procedure 744
1. Install the Quad BNC Adapter Module to Intelligent NE (Host) Shelf
1.) The Quad BNC Adapter Module, ADTRAN P/N 1181007L1 to the rear of the
Intelligent NE (Host) Shelf that contains the Total Access 3000/3010 OC-3
List 2 MUX, ADTRAN P/N 1181031L2.
for details go to DLP-708
NOTE
The Dual and Quad BNC Adapter Modules are attached to the backplane of
the Total Access 3000/3010 in the same manner.
2 Install the Dual BNC Adapter Module to Expansion Shelves (Client)
Installing Dual BNC Adapter Module to Expansion Shelves (Client)
3. Install High Speed Cabling from Intelligent NE to Expansion Shelves
1.) Use a BNC ended male-to-male high speed cable of proper length to connect
to the female BNC connector labeled TX on port 1 (located closest to the
backplane) on the Quad BNC Adapter Module that is installed on the rear of
the Intelligent NE (Host) shelf.
2.) Connect the other end of this cable to the female BNC connector labeled RX
on the Dual BNC Adapter Module that is installed on the rear of the first
Expansion Shelf.
3.) Use a BNC ended male-to-male high speed cable of proper length to connect
to the female BNC connector labeled RX on port 1 (located closest to the
backplane) on the Quad BNC Adapter Module that is installed on the rear of
the Intelligent NE (Host) shelf.
