6TANTP514-1E
TOTAL ACCESS
3000/3010
NTP-514
Page 8 of 12
© 2002, ADTRAN, Inc.
Total Access
®
3000/3010 System Manual
Perform Steps Below in the Order Listed
e.) Set Options 2 and 3, BER Threshold and BER Interval
(see Table 2).
f.) Back out of the menu for the MAIN slot and access the
HTU-C in the even-numbered (AUX) slot.
g.) Select Option 7, Protection Configuration.
h.) Option 1, Protection Mode, will have been set to AUTO.
If you desire to provision a different HLSS mode, select
Option 1, and choose between Auto, Manual Aux,
Manual Main or Auto Hold.
i.) Set Options 2-7 as desired on the AUX unit
(see Table 2).
5.) From the provisioning menu of the AUX circuit, reset the AUX unit to OOS-M.
6.) Logoff the system.
a.) From the Total Access Menu, select Option 7, Logoff,
and press <Enter>.
b.) From the Exit and Logoff screen, select “Y” and press
<Enter>.
1.6 Install the Dual-slot Stand-alone Housing
See the associated Installation and Maintenance practice, P/N 61245034L1-5, for
mounting and wiring instructions.
NOTE
Ensure the customer equipment is correctly wired to the “Main” DS1 terminal
block inside the H-LSS housing or utilizes the “MAIN DS1” RJ-48 jack on
the back of the housing.
1.7 Install the HTU-R
The HTU-R terminates local loop HDSL signals originating from the Central Office
(CO) unit and transforms the HDSL signal into traditional DS1 signals to be delivered
to the customer.
1. Install the HTU-R into the Dual-slot Remote Housing
Electronic modules can be damaged by static electrical discharge. Before
handling modules, wear an anti-static discharge wrist strap to prevent damage to
electronic components. Place modules in anti-static packing material when
transporting or storing. When working on modules, always place them on an
approved anti-static mat that is electrically grounded.
