Perform Steps Below in the Order Listed
Total Access
®
3000/3010 System Manual
© 2002, ADTRAN, Inc.
1.) Connect the individual 4-wire HDSL circuits to the HDSL terminal
block inside the Dual slot remote housing. The 4-wire MAIN circuit
will connect to the Loop 1 and Loop 2 terminals labeled “MAIN” and
the 4-wire AUX circuit will connect to the Loop 1 and Loop 2 terminals
labeled “AUX.”
2.) Gently but firmly push the HTU-R into the lower dual slot remote
housing slot. Repeat this step for the second HTU-R in the upper slot.
3.) The HTU-Cs will transfer provisioning data to the HTU-Rs upon power-
up. Some provisioning of the HTU-R, however, may be necessary due to
hardware dipswitches and jumpers. See the Installation and Maintenance
practice for the specific HTU-R utilized by your company.
4. Upon provisioning of the HTU-Rs, the faceplate LEDs should read as shown in
Table 3.
Table 3. Faceplate LED Indications
)NIAM(C-UTH
neerGgnihsalFwolS-RWP
nO-XSD
ffO-TST
neerG-2PL,1PL
deR-MLA
neerG-TCA
)XUA(C-UTH
neerGgnihsalFwolS-RWP
nO-XSD
ffO-TST
neerG-2PL,1PL
ffO-MLA
ffO-TCA
)NIAM(R-UTH
neerG-2PL,1PL
ffO-1SD
deR-MLA
neerGrowolleY-FS/FSE
neerGrowolleY-IMA/SZ8B
ffO-KBL
)XUA(R-UTH
neerG-2PL,1PL
ffO-1SD
deR-MLA
neerGrowolleY-FS/FSE
neerGrowolleY-IMA/SZ8B
ffO-KBL
