Total Access
®
3000/3010 System Manual
6TADLP717-1E
TOTAL ACCESS 3000/3010
DLP-717
Page 2 of 4
© 2002, ADTRAN, Inc.
Perform Steps Below in the Order Listed
1.2 Detailed Level Procedure 717
1.2.1 To set the Target ID (TID) in the system:
1. Logon to the system
For details, go to: DLP-716.
2. From the Total Access 3000/3010 main menu, select option 1, System
Controller, and press <Enter>.
3. From the System Controller menu, select option 2, Provisioning, and press
<Enter>.
4. From the Provisioning menu, select option 5, TL1, and press <Enter>.
5. From the TL1 menu, select option 2, Target ID, and press <Enter>.
6. Enter the 11 character Target ID and press <Enter>.
The Target ID issued from TIRKS will be an 11 digit code similar to the following
format: HTVLALEXD01
Where:
HTVL designates the city
AL designates the state
EX identifies the Central office or remote terminal
D identifies equipment type (“D” is administrative equipment)
01 identifies the piece of equipment of that type at the CO
7. Press <Esc> to return to the main menu.
1.2.2 To set the Shelf Number, continue with the following:
1. From the Provisioning menu, select option 5, TL1, and press <Enter>.
2. From the TL1 menu, select option 1, Shelf Number/Shelf ID, and press
<Enter>.
3. Input the Shelf Number and press <Enter>.
NOTE
The Shelf Number is a numerical value between 1 and 254 (inclusive) and is
used to identify the shelf as distinct on the RS-485 bus. Only 16 shelves are
supported on a single RS-485 bus; therefore, there should not be matching
Shelf Numbers on the same RS-485 bus.
4. Press <Esc> to return to the main menu.
