Total Access
®
3000/3010 System Manual
6TADLP720-1E
TOTAL ACCESS 3000/3010
DLP-720
Page 2 of 4
© 2002, ADTRAN, Inc.
Perform Steps Below in the Order Listed
1.2 Detailed Level Procedure 720
1. Verify That the Shelf Under Test is Powered
Verify that the shelf to be tested is powered with -48V.
2. Seat the TAM card in the Slot to be Tested
Seat the TAM card in the slot to be tested. If the entire shelf needs to be tested,
start with slot 1. This test may only be performed on the access module slots
labeled 1 through 28. This test may not be performed on the SCU slot or the A and
B MUX slots.
3. Connect the Test Jack to DSX-1 IN A
Locate the position on the DSX-1 cross connect which corresponds to DSX-1 A
for the slot under test. Plug the test jack into the jack labeled IN.
4. Ground Tip and Check for Green Pair 7 LED
Connect Tip of the test jack to frame ground. Visually verify that the LED on the
TAM card labeled Pair 7 is lit green. No other LED on the TAM card should light.
If the LED lights up red, this indicates that the Tip and Ring wires are reversed.
No LED lit indicates no continuity on the Tip.
5. Ground Ring and Check for Red Pair 7 LED
Disconnect the test jack’s Tip from Ground. Connect the Ring of the test jack to
frame ground. Visually verify that the LED on the TAM card labeled pair 7 is lit
red. No other LED on the TAM card should light. If the LED lights up green, this
indicates that the Tip and Ring wires are reversed. No LED indicates no continuity
on the Ring.
6. Connect the Test Jack to DSX-1 OUT A
Move the test jack from the IN jack to the OUT jack of the same DSX-1 cross
connect position.
7. Connect tip to Ground and Check for Green Pair 8 LED
Connect the Tip of the test jack to frame ground. Visually verify that the LED on
the TAM card labeled Pair 8 is lit green.
8. Connect Ring to Ground and Check for Red Pair 8 LED
Disconnect the test jack’s Tip from ground. Connect the Ring of the test jack to
frame ground. Visually verify that the LED on the TAM Card labeled pair 8 is lit
red.
