Total Access
®
3000/3010 System Manual
6TAPRP401-1E
TOTAL ACCESS 3000/3010
PREP-401
Page 4 of 10
© 2002, ADTRAN, Inc.
The actual wiring scheme for connecting the shelf to the DSX-1 cross connect is given
in the Application Guide for each of the above applications.
To connect the shelf to a standard DSX-1 cross connect, use 24 AWG, 28-pair/22-pair
twisted, shielded transmission cables with 64-pin/50-pin female connectors on the
shelf end. Two such cables are required for each group of 28/22 connections to the
cross connect.
Table 1. DSX-1 Connections
Total Access Platform DSX-1 Cross-Connect Positions
TDM Application Total Access 3000 Total Access 3010
Standard DSX-Fed (APP-301) 56 44
HDSL/T1 DSX-Fed (APP-302) 28 22
DSL Mode DSX-Fed (APP-305) 28 22
QFO-C only DSX-Fed (APP-306) 56 44
Standard Combo-Fed (APP-307) 56 44
HDSL/T1 only Combo-Fed (APP-308) 28 22
DSL Mode Combo-Fed (APP-309) 28 22
