Custom cables designed for this application may be ordered to length through
Telephone Services, Inc. (TSI) of Florida. These cables have the shield connected to
pin-64/pin-50 of the connector. Since the Total Access 3000/3010 shelf provides a
ground connection on pin-64/pin-50 of each pair connector, simply plugging these
cables into the shelf provides proper grounding of the cable shield. TSI Part Numbers
for these cables are listed in Table 5.
Data Cable Requirement TSI Model Number
Total Access 3000
Connecting to a standard wire wrap terminal block CA4-xxxx-D12-000-1
Connecting to a 64-pin connectorized terminal block CA4-xxxx-D13-000-1
Total Access 3010
Connecting to a standard wire wrap terminal block CA4-xxxx-102-T00-2
Connecting to a 50-pin connectorized terminal block CA4-xxxx-104-T00-2
Table 5. TSI Amphenol Cable Model Number for MDF Connections
Where “xxxx” represents the length of the cable in feet. For example, a 210-foot standard cable for wiring to a connectorized
terminal block would be CA4-0210-D13-000-1.
1.6.2 Horizontal-side Terminal Blocks
As shown in the Application Guides of this system manual, each Total Access 3000/
3010 shelf wires out to its own terminal block on the side of the MDF. A separate
terminal block location on the side of the MDF should be reserved for each shelf to be
installed.
Telzon terminal blocks custom designed for use with the Total Access 3000/3010 shelf
are available from Thomas & Betts. These terminal blocks are wired and labeled to
match the diagrams given in the Application Guides and fit any standard MDF
universal mounting. These terminal blocks are connectorized for easy installation and
may be used with the TSI cable listed above (CA4-xxxx-D13-000-1).
The type of terminal block and number of cables needed for each system application is
given in Table 5.
Telzon part numbers for these terminal blocks are:
• 4-Connector Standard Block (6 inches deep): 408-1064-301
• 4-Connector Compact Block (4.75 inches deep): 408-1064-341
• 6-Connector Standard Block (6 inches deep): 448-1066-301
The terminal block for each shelf should be mounted on the MDF and the MDF cables
should be attached as shown in the Application Guide section of this system manual.
The other end of the cable should be routed to the anticipated location of the shelf and
labeled to indicate the terminal block location and which connector is attached at the
other end (A, B, C, etc.).
