6TANTP513-1E
TOTAL ACCESS
3000/3010
NTP-513
Page 5 of 8
Perform Steps Below in the Order Listed
For Details Go To:
Total Access
®
3000/3010 Systems Manual
© 2002, ADTRAN, Inc.
NOTE
The condition of the ALM, DSX and DS1 LEDs depends upon the status of
the equipment on the ends of the installed circuit. If both terminations of the
circuit are appropriately configured and prepared to pass data, the HTU-C
ALM LEDs will be out, the HTU-C DSX LEDs will be green (MAIN) and Off
(AUX), the MAIN HTU-R DS1 LED will be green and ALM off, while the
AUX HTU-R DS1 will be off, and ALM red.
Table 1. Faceplate LEDs
)NIAM(C-UTH
neerGgnihsalFwolS-RWP
ffO-XSD
ffO-TST
neerG-2PL,1PL
deR-MLA
neerG-TCA
)XUA(C-UTH
neerGgnihsalFwolS-RWP
ffO-XSD
ffO-TST
neerG-2PL,1PL
ffO-MLA
ffO-TCA
)NIAM(R-UTH
neerG-2PL,1PL
ffO-1SD
deR-MLA
neerGrowolleY-FS/FSE
neerGrowolleY-IMA/SZ8B
ffO-KBL
)XUA(R-UTH
neerG-2PL,1PL
ffO-1SD
deR-MLA
neerGrowolleY-FS/FSE
neerGrowolleY-IMA/SZ8B
ffO-KBL
To Next Page
