6TANTP514-1E
TOTAL ACCESS 3000/3010
NTP-514
Page 11 of 12
Perform Steps Below in the Order Listed
Total Access
®
3000/3010 System Manual
© 2002, ADTRAN, Inc.
1. Disabling protection switching.
1.) Access the AUX HTU-C and select Option 2, Provisioning, from the
HDSL Main Menu.
2.) From the Provisioning menu, choose the Service State option.
3.) Select Option 3, Out Of Service-Unassigned.
4.) Escape out of the AUX HTU-C menus and proceed to the MAIN
HTU-C menu.
5.) From the Main Menu, select Option 7, Protection Configuration.
6.) From the Protection Configuration menu, select Option 1, Protection
Mode.
7.) Choose Option 2, Disable.
NOTE
There is no provisioning required at the HTU-Rs to remove protection
switching capability. Upon completion of the above procedure, the MAIN
circuit is an independent, non-protected HDSL circuit. The AUX circuit is
also now independent, with protection switching disabled, and currently
OOS-U.
2. Adjust wiring at Dual remote housing. Once protection switching has been
disabled in the HTU-Cs, the housing is internally wired to provide a DS1 signal
to both the MAIN DS1 and AUXILIARY/TEST DS1 RJ-48 jacks. Connect the
customer’s equipment to the AUX RJ-48 jack or the AUX DS1 terminal strip in
the housing to complete a second independent HDSL circuit.
NOTE
DSX-1 DS3 multiplexer channel mapping to the even-numbered (formerly
AUX) slot in the TA3000 chassis will not automatically be restored.
Assignment of an embedded DSX-1 in the DS3 data stream to the even slot
will have to be made prior to using the slot as a DS3-fed HDSL circuit.
