Perform Steps Below in the Order Listed
Figure 1. Total Access 3000/3010 Alarm Contacts
DO NOT REMOVE
BEFORE INSERTION
INTO PCB
AMP
AMP
TOTAL ACCESS
CHASSIS
TERM
IN
TERM
OUT
9
P3
NO C NC NO C NC
AUX1 AUX2
P21
CRI-V
NO C NC NO C NC NO C NC
MAJ-V MIN-V
P1
CRI-A
NO C NC NO C NC NO C NC
MAJ-A MIN-A
