ADTRAN Total Access 3000 - Page 304

Total Access
®
3000/3010 System Manual
6TADLP712-1E
TOTAL ACCESS 3000/3010
DLP-712
Page 4 of 4
© 2002, ADTRAN, Inc.
Perform Steps Below in the Order Listed
Figure 1. Total Access 3000/3010 Interbank Connections
IN OUT
A B A B
RS-485
HOST
CHASSIS
1
A B A B
IN OUT
RS-485
CLIENT
CHASSIS
2
IN OUT
A B A B
RS-485
CLIENT
CHASSIS
15
UP TO 16 CHASSIS
IN OUT
A B A B
RS-485
P2
P2
P2
P2
CLIENT
CHASSIS
16
