Total Access
®
3000/3010 System Manual
6TADLP721-1E
TOTAL ACCESS 3000/3010
DLP-721
Page 3 of 4
© 2002, ADTRAN, Inc.
Perform Steps Below in the Order Listed
NOTE
Steps 11 through 18 should only be performed if the shelf has Pair 3 and Pair
4 connectors wired to the MDF.
11. Connect Tip of Pair 3 to Ground
Move the test jack from the Pair 2 position to the Pair 3 position for the same slot.
Connect Tip of Pair 3 to frame ground.
12. Check for Green Pair 3 LED
Visually verify that the LED on the TAM card labeled Pair 3 is lit green.
13. Connect Ring of Pair 3 to Ground
Disconnect Tip of Pair 3 from ground. Connect Ring of Pair 3 to frame ground.
14. Check for Red Pair 3 LED
Visually verify that the LED on the TAM card labeled Pair 3 is lit red.
15. Connect Tip of Pair 4 to Ground
Move the Test Jack from the Pair 3 position to the Pair 4 position for the same slot.
Connect Tip of Pair 4 to frame ground.
16. Check for Green Pair 4 LED
Visually verify that the LED on the TAM card labeled Pair 4 is lit green.
17. Connect Ring of Pair 4 to Ground
Disconnect Tip of Pair 4 from ground. Connect Ring of Pair 4 to frame ground.
18. Check for Red Pair 4 LED
Visually verify that the LED on the TAM card labeled Pair 4 is lit red.
NOTE
Steps 19 through 22 should only be performed if the shelf has the Pair 5
connector wired to the MDF.
19. Connect Tip of Pair 5 to Ground.
Move the test jack from the Pair 4 position to the Pair 5 position for the same slot.
Connect Tip of Pair 5 to frame ground.
20. Check for Green Pair 5 LED.
Visually verify that the LED on the TAM card labeled Pair 5 is lit green.
21. Connect Ring of Pair 5 to Ground.
Disconnect Tip of Pair 5 from Ground. Connect Ring of Pair 5 to frame ground.
