Total Access
®
3000/3010 System Manual
6TADLP726-1E
TOTAL ACCESS 3000/3010
DLP-726
Page 3 of 6
© 2002, ADTRAN, Inc.
Perform Steps Below in the Order Listed
Link Status Value Meaning
0x00 No Clear-To-Send (CTS), No Data Carrier Detect (DCD)
0x10 Clear-To-Send (CTS) present, No Data Carrier Detect (DCD)
0x40 Data Carrier Detect (DCD) present, No Clear-To-Send (CTS)
0x50 Normal, CTS and DCD both present
Table 1. Link Status
Frame Status Value Meaning
0x0 to 0x100 Normal state. Gives the number of frame buffers in use.
This number will normally be either 0x0, 0x1, or 0x2 but
may go higher under heavy traffic.
0x101 Idle
0x102 Setup
0x103 Frame Reject
0x106 Reject Sent
0x108 Busy
0x109 Remote Busy
Table 2. Frame Status Value
Server Status Value Meaning
0x0 to 0x100 Normal state. Gives the number of frame buffers in use for
that particular server. This number will normally be either
0x0, 0x1, or 0x2 but may go higher under heavy traffic.
0x104 Server Idle and Ready
Table 3. Frame Status Value
To Next Page
