10.19. Sun visor (optional)

Sun visors are available for the devices DLT-V8310 and DLT-V8312.

Fig. 10.12: DLT-V83 with sun visor

Technical data

Material Aluminum, powder coated

Weight of sun visor DLT-V8310 300 g

Weight of sun visor DLT-V8312 357 g

Screws DIN912 M6x10 A2 TufLok

Washers DIN 1440-A6-A2

Tightening torque 10 Nm
