Advantech-DLoG DLT-V8312 - Fig. 14.9: Dimensions DLT-V8315 Side View (Standard Resisitive Touchscreen)

To Next Page

To Previous Page

Technical data

Page 150 of 178 DLT-V83 Series Manual V1.31 Advantech-DLoG

Side view

Dimensions without add-ons (in mm):

Example:

Fig. 14.9: Dimensions DLT-V8315 side view (standard resisitive touchscreen)

The installation depth of the devices varies depending on the type of touchscreen:

Device type Building depth (side view)

DLT-V8315 standard resistive touchscreen 98 mm (see figure)

DLT-V8315 PCT Touchscreen 97 mm
