Operating the touchscreen, front keys
Advantech-DLoG DLT-V83 Series Manual V1.31 Page 37 of 178
Right on the device:
Key Explanation
Page Up / Line Up (switch with <Shift> key)
Page Down / Line Down (switch with <Shift> key)
Home / Backwards (switch with <Shift> key)
End / Forwards (switch with <Shift> key)
Special keys <S1> and <S2>
These keys are configured with the "DLoG Config" program;
the associated manual is available in the Download Center at
www.advantech-dlog.com.
<Esc> key
<Enter> key
Below on the device:
Key Explanation
…
Function keys and numbers 0 to 9, backspace
<Shift> pressed: Key function marked in grey is active
<Shift> not pressed: Key function marked in white is active.
The function keys are configured with the "DLoG Config" program,
the associated manual is available in the Download Center at
www.advantech-dlog.com.
