200 Agilent 1260 Infinity DAD and MWD User Manual
9
Maintenance
Correcting Leaks
Correcting Leaks
1 Use tissue to dry the leak sensor area and the leak pan.
2 Observe the capillary connections and the flow cell area for leaks and
correct, if required.
Figure 61 Observing for Leaks
3 Replace the front cover.
When If a leakage has occurred in the flow cell area or at the heat exchanger or at the capillary
connections
Tools required p/n Description
Tissue
Wrench, 1/4 inch
for capillary connections
5043-0915 Fitting mounting tool
for bio-inert capillaries
Preparations Remove the front cover.
/HDNSDQ
/HDNVHQVRU
