Agilent 5110/5100 ICP-OES Service Manual Agilent Restricted 259
9 iTroubleshoot/Parts Predict
Problem Solving Table
Gas Control Gas Control Ready LED Red Gas Control not calibrated Replace Gas Control Module G8010-60800
Gas Control Gas Control Ready LED Red Plasma Gas Flows incorrect Replace Plasma Gas Module G8010-60826
Gas Control Gas Control LED Red Gas Control Module Fault Replace Gas Control Module G8010-60800
Instrument Control Instrument won't initialize Firmware Error Replace P500 PCA G8010-65204
Instrument Control Instrument won't initialize Firmware Error Reload Firmware
Instrument Control Instrument won't initialize Control Board Fault Replace Instrument Control PCA G8010-65200
Instrument Control Instrument won't initialize MPM Failed Replace MPM G8010-67300
Instrument Control Electronics Ready LED Red Communications Failure Replace Instrument Control PCA G8010-65200
Instrument Power Soft Switch LED flashing at 4Hz MPM Failed Replace G8010-67300
Instrument Power Soft Switch LED flashing at 4Hz Power Supply inadequate Verify Power Supply
Instrument Power Soft Switch LED off Instrument Circuit Breaker Check Circuit Breaker On
Instrument Power Soft Switch LED off Mains Power Supply issue Verify Customer Power Supply
Instrument Status LED Status LED Flashing Yellow Host not connected Check for Communication to PC
Instrument Status LED Status LED Red Firmware Error Reload Firmware
Instrument Status LED Status LED Yellow Interlock not satisfied Check RF Door, Torch Handle,
Water Flow
Instrument Status LED Status LED Yellow Interlock not satisfied Replace Instrument Control PCA G8010-65200
Low Intensities Low Intensities at high/Low
Wavelengths (May not
Calibrate)
Argon Ratio incorrect Allow instrument to warm up for
4 hours
Low Intensities Low Intensities at high/Low
Wavelengths (May not
Calibrate)
Argon Ratio incorrect Polychromator temperature
control failing - (Optics Ready
LED red section)
Low Intensities Low Intensities at high/Low
Wavelengths (May not
Calibrate)
Argon Ratio incorrect Pre Optics or Polychromator
requires realignment
Low Intensities Low Intensities at high/Low
Wavelengths (May not
Calibrate)
High Dark Current values Recalibrate Detector - Check for
light leak, shutter sticking
Low Intensities Low Intensities at high/Low
Wavelengths (May not
Calibrate)
High Dark Current values Realign Optics, Check Camera
offsets using PolyAlign S/W
Low Intensities Low Intensities at high/Low
Wavelengths (May not
Calibrate)
Leaking fitting Check Nebulizer, Pump tubing,
Sampler, Bubbles in Tube
Low Intensities Low Intensities at high/Low
Wavelengths (May not
Calibrate)
Parameters not optimized Optimize Nebulizer flow,
Viewing height, Plasma Power,
Pump Speed
Low Intensities Low Intensities at high/Low
Wavelengths (May not
Calibrate)
Sample Delivery issue Check Pump tube tension or
stretched pump tube
3710034600,
3710046900
Low Intensities Low Intensities at high/Low
Wavelengths (May not
Calibrate)
Sample Intro blockage Nebulizer Blocked - Clean G8010-60255
Table 1
Symptom Area Problem Problem Description Solution Part Number(s)
