108 5977B Series MSD Troubleshooting and Maintenance Manual
4 General Maintenance
The MSD can now be stored or moved. The foreline pump cannot be
disconnected; it must be moved with the MSD. Ensure the MSD remains
upright, and is never tipped on its side or inverted.
Figure 9 Side plate thumbscrews
Front thumbscrew
Rear thumbscrew
The MSD must remain upright at all times. If you need to ship your MSD to another
location, contact your Agilent Technologies service representative for advice about
packing and shipping.
