16 5977B Series MSD Troubleshooting and Maintenance Manual
1 Introduction
MSD Hardware Description
Figure 1 is an overview of a typical GC/MSD system.
Figure 1 Agilent 5977B Series GC/MS system
ALS
GC control panel
7890 GC
5977B Series
MSD
MSD power switch
GC power
switch
Front panel LED
