Agilent Technologies 5977B Series Troubleshooting And Maintenance Guide

114 5977B Series MSD Troubleshooting and Maintenance Manual
4 General Maintenance
To Install the Exhaust Filter on the IDP3 Dry Pump
Materials needed
• Exhaust filter (G3170-80041)
Procedure
1 Disconnect the foreline pump exhaust hose from the adapter.
2 Unscrew the adapter from the pump.
3 Screw the filter on to the pump.
Figure 12 IDP3 pump with exhaust filter


Exhaust filter
Exhaust hose
Hose adapter
