Agilent Technologies 5977B Series Troubleshooting And Maintenance Guide

198 5977B Series MSD Troubleshooting and Maintenance Manual
7 Analyzer
7 CI drawout plate G1999-20446
8 CI ion source heater block assembly G3870-60415
9 Entrance lens G3170-20126
10 CI ion source body G3170-20430
11 CI ion focus lens G1999-20443
12 CI repeller G1999-20432
13 CI filament G7005-60072
14 Dummy filament G1999-60454
Not labeled Curved washer 3050-9082
Not labeled Flat washer 3050-1374
Tab le 15 Parts list for the CI ion source (Figure 47 on page 197) (continued)
Item number Item description Part number
