Tab le 16 Front panel Instrument Status LED codes
Instrument status LED code
Ready Solid green
Acquiring data Blinking green
Not ready Solid yellow
Not connected to DS (system idle) Solid blue
Ready and not connected to DS Solid yellow for 3 sec, quick double blink
Start up (prior to FW load) Blinking red
Fault Solid red
