Agilent Technologies 5977B Series

Electronics 8
5977B Series MSD Troubleshooting and Maintenance Manual 223
Figure 53 Back panel connections
Remote start
Primary fuses
Power cord
LAN
High vacuum control
High vacuum power
Foreline pump
RS-232 Serial B
power cord
RS-232 Serial A
GC communication
High vacuum gauge connector
