242 5977B Series MSD Troubleshooting and Maintenance Manual
9 Parts
Extractor ion source
Tab le 27 Parts list for extractor ion source (Figure 63)
Item number Item description Part number
1 Setscrews G3870-20446
2 Screws G3870-20021
3 Source body G3870-20440
4 Extractor lens G3870-20444
5 Extractor lens insulator G3870-20445
6 Filaments G7005-60061
7 Spring washer 3050-1301
7 Flat washer 3050-0982
8 Lens insulator G3870-20530
9 Entrance lens G3170-20126
10 Ion focus lens 05971-20143
11 Repeller insulator G3870-20133
12 Repeller G3870-60171
13 Flat washer 3050-0891
14 Belleville spring washer 3050-1301
15 Repeller nut 0535-0071
16 Source heater block assembly G3870-60177
17 Insulator G1099-20133
