341 Micro-cell Electron Capture Detector (µ-ECD)
Replacement procedures
10 of 26
Jun 2001
Detectors
Agilent 6890 Gas Chromatograph Service Manual
Figure 341-8 Proper configuration of the column and makeup gas tubing
NEED GRAPHIC
Makeup gas
adapter
Column nut
Column
70 to 72 mm
Coil loops around bottom
of detector and makeup
gas adapter connection.
Microbore
Column
Column does
not protrude
