Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Inlets 1310
Pneumatic carrier assembly G1585A
Pneumatic carrier assembly G1585A
Note Minimum Replacement Level is G1530-80790
Description Part no. Qty.
1. Flow support bracket G1530-01220 1
2. Flow module back-up plate G1530-00580 1
3. Flow carrier assy. G1530-80790 2
4. PPIP manifold assy, 0 to 100 psi (with inlet) G1543-60500 1
5. Spacer, pressure gauge 19243-40010 2
6. Screw, M4 × 25 mm, Torx T-20 0515-2712 2
7. Screw, M4 × 12 mm, Torx T-20 0515-2496 12
8. Flow cover G1530-01240 1
9. S/SL manifold assy., 0 to 30 psi G1544-60500 1
10. Nut, hex w/lkwr 0535-0043 2
11. Reg/Gauge assy. (order part no. G1577A) 19246-60640 1
12. Chemical trap bracket 05890-00810 1
13. Screw, machine, flat head, M4 × 10, Torx T-20 0515-2725 2
14. Chemical trap assy. 05890-80710 2
15. Label plate, blank G1530-90705 1
Label plate, PPIP G1530-90740 NS
Label plate, S/SL G1530-90720 NS
