1310 Inlets
Programmed temperature vaporization inlet
22 of 36
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Programmed temperature vaporization inlet
Description Part no. Qty.
1. Septumless head G2617-60507 1
2. Septum head* G2618-80500 1
3. Septum nut* 18740-60835 1
4. PTV inlet assy G2617-60506 1
5. PTV cryo insulator (not shown) G2617-60510 1
6. PTV LCO
2
cooling jacket G2617-60508 1
7. PTV LN
2
cooling jacket G2619-60501 1
8. Silver seal (5/pk) 5182-9763 1
9. Graphpack inlet adapter 1
0.2 mm Column ID 5182-9754
0.25–0.33 mm Column ID 5182-9761
0.53 mm Column ID 5182-9762
10. Ferrules for graphpack inlet 1
0.2 mm Column ID (10/pk) 5182-9756
0.25 mm Column ID (10/pk) 5182-9768
0.32 mm Column ID (10/pk) 5182-9769
0.53 mm Column ID (10/pk) 5182-9770
11. Split nut for inlet adapters 5062-3525 1
12. Screws, M3 × 0.5 × 3 mm 3
13. PTV insulation block G2617-20510 1
14. PTV septumless gang weldment G2617-80500 1
15. PTV septum gang FTG weldment G2618-80500 1
16. Replacement filter kit G1544-80530 1
17. PTV front trap assy G2617-80520 1
18. Trap nut G1544-20650 1
19. Teflon ferrule (needle seal) 5182-9748 1
20. Kalrez seal** 5182-9759 1
21. Valve body** 5182-9757 1
22. Pressure spring** 5182-9758 1
23. Viton seal 5182-9775 1
24. Sealing element 5182-9760 1
25. PTV column adapter tube G2617-80550
26. 3-D Graphpak ferrules, not shown (5/pkg) 5182-9749
27. 3-D Graphpak assembly Tool, not shown G2617-80540
*See the Agilent chemical analysis consumables and accessories catalog for Merlin
assemblies.
**Service kit, part no. 5182-9747, consists of items 20, 21, and 22.
