1320 Detectors
Electron Capture Detector (ECD)
2 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Electron Capture Detector (ECD)
Description Part no. Qty
1. ECD top cover G1533-00040 1
2. ECD signal wire assembly 19233-60635 1
3. Anode/Ferrule/Nut assembly (specific license required) 19233-67010 1
4. ECD thermal cover G1533-00030 1
5. Thermal cover clip 19233-00095 1
6. Top cover insulation G1533-00020 1
7. Screw, M4 × 10 mm, Torx T20 0515-2495 3
8. Clamp, interconnect 19231-00040 1
9. Captive screw, detector pallet, M4 × 20 mm, T20, Torx 1390-1024 4
10. Detector pallet G1531-40020 1
11. Screw, M4 × 45 mm, Torx T20 0515-2484 2
12. Electron Capture Detector assembly: 1
– General licensed ECD, new G1533-60576 -
– General licensed ECD, rebuilt G1533-69576 -
– Japan only ECD, new G1533-60730 -
– Japan only ECD, rebuilt G1533-69730 -
13. Detector block insulation G1533-00010 1
14. Lower seal insulation G1533-00080 1
15. Screw, M4 × 12 mm, Torx T20 0515-2496 1
16. ECD make-up gas adapter weldment: G1533-80565 1
– Gigabore liner 19233-20625 -
– End cap 19233-20755 -
17. Ferrules, capillary columns: 1
– No hole (plug), graphitized-vespel 5181-7458 1
– Graphite, 0.5 mm id (10/pkg) 5080-8853 -
– Graphite, 1.0 mm id (10/pkg) 5080-8773 -
18. Capillary column nut (2/pkg) 5181-8830 1
19. Screw, M4 × 12 mm, Torx T20, chromeplate 0515-2711 3
20. ECD interconnect assembly G1533-60510 1
21. ECD signal board G1533-60010 1
22. ECD interface board G1533-60020 1
23. Heater/Sensor assembly G1533-60625 1
24. Upper heated block G1533-20525 1
25. Lower heated block 19233-20515 1
26. ECD mounting plate G1533-00050 1
27. Nut warmer insulation assembly 19234-60715 3
28. Nut warmer cup assembly 19234-60700 1
29. Tubing tygon, (order 30 inches) 0890-0934 30 inches
30. Vent elbow 19303-20590 1
31. Tubing adapter 5020-8231 1
