1320 Detectors
Electron Capture Detector manifold assembly
4 of 30
Jun 2001
Illustrated Parts Breakdown
Agilent 6890 Gas Chromatograph Service Manual
Electron Capture Detector manifold assembly
Description Part no. Qty
1. EPC ECD manifold assembly G1533-60520 1
2. Non-EPC ECD manifold assembly G1533-60500 1
3. Screw, M3 × 25 mm, Torx, T10 0515-0683 6
4. Screw, M3 ×.5 × 8 mm, Torx, T10 0515-0655 2
5. ECD make-up gas assembly (Manual ECD) G1533-60600 1
5A. Pressure regulator, 0-100 psi (Manual ECD) G1531-60630 1
5B. ECD manifold regulator brazement (Manual ECD) G1533-80530 1
NS Chemical traps (Manual ECD) G1533-80540 2
